1 Brass Solenoid Valve 0.5-50 Bar 2/2 Normally Closed PU225X-08

Brand: Shako Co Ltd

Model: PU225X08

Width 70.00
Height 126.50
Length 100.00

£156.41 £192.95
Price Ex Vat: £130.34

25 in stock


1 inch high pressure brass solenoid valve, Shako PU225X-08
Function: 2/2 way normally closed
Operation: Pressure assisted piston, Requires Min 0.5 Bar differential
Port: 1 BSP, option NPT or Rc thread.
Pressure: 0.5 to 50 Bar (tested 75 Bar)
Body: Brass
Internals: Stainless Steel
Piston: stainless steel
Seals: Piston PTFE, armature NBR
Media: air, water, light oil and most other non-corrosive fluids under 50CST and gases compatible with materials of construction.
Orifice: 25.0mm
Kv flow factor: 171.6 L/Min based on water with 1 Bar pressure drop.
Coil: 15 Watt Nass Magnet IP65 Class H 100% duty rated DIN43650A
Protection: IP65 with connector (Included)
Coil option: ATEX EExmIIT4 Temperature Class T4 T130°C Ex mb IIC T4 and Gb Ex mb tb IIIC T130°C Db for hazardous area 21 and 22.
Voltages: 12vDC, 24vDC, 48vDC, 110vDC, 220vDC or 12vAC, 24vAC, 48vAC, 110vAC, 240vAC or 380vAC 50/60hz.

Unique design protected by Patent: Taiwan:M391595, USA GB2480100
