Key Features

✓ 316 stainless steel construction

✓ Male run tee configuration

✓ Three-way pneumatic connection

✓ Twin push-in tube connections

✓ Tube sizes from 4mm to 12mm

✓ 1/8" to 1/2" BSPT threads

✓ Optional NPT threads available

✓ Viton seals as standard

✓ Pressure rated to 10 Bar

✓ Temperature 0°C to +180°C

✓ Push-to-connect tube installation

✓ Compact space-saving design

✓ Excellent corrosion resistance

✓ Suitable for polyurethane tube

✓ Suitable for nylon tubing

✓ Ideal for pneumatic systems

✓ Shako S6PD Series fitting

Datasheets

Description

316 Stainless Steel Male Run Tee Push-In Fitting – S6PD

The Shako S6PD is a compact 316 stainless steel male run tee push-in fitting designed to connect two pneumatic tubes to a male threaded port, providing a convenient 3-way connection for compressed air and compatible fluid systems.

The run tee configuration positions the two push-in tube connections at 90° to each other, with the male threaded connection forming the third port. This makes the S6PD particularly useful for branching pneumatic lines directly from cylinders, valves, manifolds and other threaded equipment.

Manufactured from corrosion-resistant 316 stainless steel with Viton seals, the S6PD provides a durable alternative to standard plastic or nickel-plated brass pneumatic fittings. It is suitable for demanding industrial environments and applications requiring improved corrosion, temperature and chemical resistance.

The push-in connections allow pneumatic tubing to be installed quickly without additional tools, while the threaded connection provides secure mounting directly into the component or process connection.

Sizes & Connections

Tube sizes: 4mm, 6mm, 8mm, 10mm and 12mm

Male threads: 1/8", 1/4", 3/8" and 1/2" BSPT

Optional NPT thread versions are also available.

Construction

Body: 316 stainless steel

Seals: Viton (FKM)

Tube: Polyurethane or Nylon

Pressure & Temperature

Maximum pressure: 10 Bar

Temperature range: 0°C to +180°C

Suitable Media

Designed primarily for compressed air and compatible gases or fluids. Media compatibility should always be checked against the 316 stainless steel body, Viton seals and tubing material.

Typical Applications

Ideal for pneumatic cylinders, control valves, manifolds, instrumentation, process equipment, food-processing machinery, industrial automation and other installations requiring a compact corrosion-resistant branch connection.

Related Products & Categories

Airline Fittings & Tubing

Stainless Steel Filters & Regulators

Stainless Steel Solenoid Valves

View Technical Specification

Technical Specification

Brand: Shako Co Ltd

Model: S6PD

Width: 30.00 mm

Height: 20.00 mm

Depth: 30.00 mm

Weight: 0.30 kg

Valve / Product Type: Fittings + Tubing

Body Material: Stainless Steel

Port Size: 4mm, M5, 1/8 thread, 1/4 thread, 6mm, 8mm, 3/8 thread, 10mm, 12mm, 1/2 thread

Pressure: 0.02 Bar (20 mBar), 0.1 Bar (100 mBar), 0.2 Bar (200 mBar), 0.3 Bar (300 mBar), 0.4 Bar (400 mBar), 0.5 Bar (500 mBar), 0.6 Bar (600 mbar), 0.7 Bar (700 mBar), 0.8 Bar (800 mBar), 1 Bar, 1.2 Bar, 1.3 Bar, 1.4 Bar, 1.5 Bar, 1.6 Bar, 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar

Seals: FKM (Viton)

Media: Air, Fluid (Non Aggressive), Gases (Non Aggressive), Water
