1 Angle seat piston valve stainless 16 Bar +200C N/Closed
£125.08
Description
1 inch Pneumatic Angle Body Piston Valve – ASPV25SS
Robust angle-seat piston valve with visual feedback and versatile actuation options for industrial fluid control applications.
Key Features
→ Function: 2/2 way, normally closed with visual position indicator
→ Operation: Pneumatic pilot 4–6 Bar (1/8 BSP)
→ Port: 1 BSP standard; optional NPT, tri-clamp, weld end, or flange
→ Pressure Ratings:
• Flow over seat (2→1): 0–16 Bar
• Flow under seat (1→2, anti water hammer): 0–8 Bar
→ Orifice: 24 mm
→ Kv Flow Factor: 236.7 L/min (water, 1 Bar ΔP)
Materials & Media Compatibility
→ Body & Internals: 316 stainless steel
→ Seals: PTFE standard; optional FKM or NBR
→ Media: Air, water, vacuum, steam, viscous fluids up to 600 cSt, corrosive acids/alkalis compatible with 316 SS and PTFE
→ Media Temp: -20°C to +200°C
→ Ambient Temp: -10°C to +80°C
Actuator Details
→ Actuator Head: 304 stainless steel standard, optional polycarbonate
→ Actuator Seals: FKM
→ Actuator Bore: 50 mm
Options & Control Accessories
→ Manually adjustable stroke limiter
→ Open position proximity switch (PS)
→ Mechanical open/closed position switches with LED (E2)
→ Modulating controller LED indication 4–20 mA IP65 ±0.2% (M1)
→ Modulating controller LED screen 4–20 mA IP66 ±0.1% (M2)
Compliance & Certification
→ HS Code: 8481807990
→ Complies with European Pressure Equipment Directive 2014/68/EU, Annex II, Category II, Group 2, Module A1
Applications: Suitable for chemical, pharmaceutical, food & beverage, water treatment, and other process systems where anti-water hammer performance and high corrosion resistance are required.
Technical Specification
Brand: Connexion
Model: ASPV25SS
Width: 50.00 mm
Height: 144.00 mm
Depth: 149.00 mm
Weight: 1.70 kg
Valve / Product Type: Air Actuated Valve, Angle Seat Valve, Proportional Modulating
Body Material: Stainless Steel
Port Size: 1 thread
Function: 2/2 Normally Closed, Proportional / Modulating
Operation: Direct Acting
Pressure: 0.02 Bar (20 mBar), 0.1 Bar (100 mBar), 0.2 Bar (200 mBar), 0.3 Bar (300 mBar), 0.4 Bar (400 mBar), 0.5 Bar (500 mBar), 0.6 Bar (600 mbar), 0.7 Bar (700 mBar), 0.8 Bar (800 mBar), 1 Bar, 1.2 Bar, 1.3 Bar, 1.4 Bar, 1.5 Bar, 1.6 Bar, 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar, 12 Bar, 13 Bar, 14 Bar, 15 Bar, 16 Bar
Seals: PTFE (Teflon)
Media: Air, Fluid (Stong Acid/Alkali), Fluid (Non Aggressive), Fluid (Slight Acid/Alkali), Gases (Non Aggressive), Gases (Slight Acid/Alakli), Gases (Strong Acid/Alkali), Oils + Fuels 50cSt Max, Steam, Fluid Thick 51>500cSt, Vacuum (Low), Vacuum (Medium), Water, Water (RO/Pure/Demin)
Options required: Anti Water Hammer, Bi-Directional Flow, Position Feedback Closed, Position Feedback Open+Closed, Position proximity switch - Open, Position indication Visual , Y Pattern
Orifice: 24mm
