Equal + unequal Tee push-in airline speed fitting 4 to 12mm
£0.65
£1.30 incl. VATDescription
ECO-Line Tee Advanced Pneumatic Push-to-Connect Fittings GPE
Metric Tube Sizes 4mm to 12mm, equal and unequal
Compact One Touch push to connect configuration allow an instant Nylon and Polyurethane tubing connection.
Construction: Body Polybutylene terephthalate (PBT), Sealing Ring & O Ring NBR, Collet (Zinc alloy), Sleeve + Lock Ring (POM), Lock claws (Stainless)
For use in pneumatic & vacuum systems
Working Pressure: 0-1MPa, 0-150 PSI, 0-10 Bar
Maximum Pressure: 1.5 MPa, 217 psi, 15 Bar
Vacuum Systems: -29.5 in Hg, -100kPa, -1 Bar
Temperature Range: -20 to +70C (-4F to +150F)
Tube: Polyurethane and Nylon
HS Code: 8467190000
Technical Specification
Brand: Connexion
Model: GPE
Width: 60.00 mm
Height: 35.00 mm
Depth: 15.00 mm
Weight: 0.10 kg
Valve / Product Type: AirLine Fittings + Tube
Body Material: Delrin (POM)
Port Size: 4mm, 6mm, 8mm, 10mm, 12mm
Seals: NBR
Media: Air, Vacuum (Low), Vacuum (Medium)
Pressure: Vacuum, 0.02 Bar (20 mBar), 0.1 Bar (100 mBar), 0.2 Bar (200 mBar), 0.3 Bar (300 mBar), 0.4 Bar (400 mBar), 0.5 Bar (500 mBar), 0.6 Bar (600 mbar), 0.7 Bar (700 mBar), 0.8 Bar (800 mBar), 1 Bar, 1.2 Bar, 1.3 Bar, 1.4 Bar, 1.5 Bar, 1.6 Bar, 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar
