Male Stud Push-In Pneumatic Fitting M5–1/2" BSPT – GPC
The Connexion GPC Series is a male stud push-in pneumatic fitting designed for fast, secure and leak-free connection of metric nylon and polyurethane air tubing to threaded pneumatic equipment.
Available with M5 and 1/8", 1/4", 3/8" or 1/2" BSPT male threads and push-in tube connections from 4mm to 12mm, the GPC range provides a compact and reliable connection for compressed air, vacuum, pneumatic control and industrial automation systems.
The one-touch push-to-connect design allows tubing to be installed simply by pushing it fully into the fitting. Stainless steel locking claws securely retain the tube, while the release sleeve allows rapid disconnection without dismantling the fitting or damaging the tube.
Fitting Function & Connection
Fitting type: Male stud straight push-in connector
Connection: One-touch push-to-connect
The GPC provides a straight connection between metric pneumatic tubing and a female threaded port.
The male threaded end screws directly into pneumatic valves, cylinders, manifolds, FRL equipment and other threaded components, while the opposite end accepts pneumatic tubing using a quick push-in connection.
No separate compression nut or tube olive is required.
Thread Sizes
Available male threads:
M5
1/8" BSPT
1/4" BSPT
3/8" BSPT
1/2" BSPT
The tapered BSPT thread provides a secure threaded connection and is supplied pre-treated with PTFE thread seal, simplifying installation and helping provide a reliable pneumatic seal.
Pneumatic Tube Sizes
Available tube outside diameters:
4mm
6mm
8mm
10mm
12mm
The product selector allows the appropriate combination of thread and tube size to be selected for the application.
Compatible Pneumatic Tubing
Designed for use with:
Polyurethane pneumatic tube
Nylon pneumatic tube
For reliable sealing and tube retention, pneumatic tubing should be cut squarely and pushed fully into the fitting until correctly seated.
Construction & Materials
Body: Nickel-plated brass
Tube seal: NBR
Tube locking claws: Stainless steel
Release sleeve: POM (polyoxymethylene)
Thread sealing: Pre-applied PTFE
The nickel-plated brass body provides good mechanical strength and corrosion resistance, while the stainless steel gripping claws securely retain the pneumatic tube under pressure.
Pressure & Vacuum Performance
Working pressure: 0 to 10 Bar
Maximum pressure: 15 Bar / 217 PSI
Vacuum capability: Down to -100 kPa / -29.5 inHg
This allows the same GPC fitting range to be used for both positive-pressure compressed air systems and industrial vacuum applications.
Operating Temperature Temperature range:
-20°C to +70°C
Actual system temperature capability should also take account of the pneumatic tube material and the medium being used.
One-Touch Tube Connection
Installation is straightforward:
Push the correctly sized pneumatic tube firmly into the fitting until fully seated.
The internal stainless steel locking claws grip the outside of the tube while the NBR sealing ring provides the pneumatic seal.
To remove the tube, depress the POM release sleeve and withdraw the tube.
This allows pneumatic circuits to be assembled, modified and maintained quickly without specialist tools.
Typical Applications
Pneumatic control systems
Industrial automation
Pneumatic solenoid valves
Air preparation equipment
FRL filter and regulator assemblies
Pneumatic cylinders
Air manifolds
Machine air supplies
Control panels
Vacuum systems
Pick-and-place equipment
Packaging machinery
Production equipment
Why Choose GPC Push-In Fittings?
The Connexion GPC Series combines a nickel-plated brass body, stainless steel tube retention and one-touch connection in a compact fitting suitable for everyday industrial pneumatic systems.
With tube sizes from 4mm to 12mm and threads from M5 through to 1/2" BSPT, the range provides numerous combinations for connecting pneumatic tubing directly to valves, cylinders, regulators, manifolds and other pneumatic equipment.
The pre-applied PTFE thread seal also saves installation time compared with fittings requiring separate thread-sealing tape or compound.
Ordering Information
Select the required combination of:
Male thread size and Pneumatic tube outside diameter before adding the fitting to your basket.
For example: 1/4" BSPT × 6mm tube
means a fitting with a 1/4" male BSPT thread and push-in connection for 6mm OD pneumatic tube.
