1/8 1/4 Brass 3/2 solenoid valve 0-15 Bar 1.5-3mm (300201)

£62.29

£88.48 incl. VAT
£51.91 ex. VAT

Brand: ERA SIB

Model: 300201

Stock: 242 in stock

Read Full Description

Description

1/8 1/4 inch 3/2 miniature brass solenoid valve 300201
Function: 3/2 way Normally closed, option normally open or universal.
Operation: direct acting
Port: 1/8 or 1/4 BSP, option NPT thread (top port 1/8 male)
Body: Brass
Internals: stainless steel
Pressure: 0 to 15 Bar depending on orifice and coil power
Orifice: 1.5mm, 2.0mm, 2.5mm and 3.0mm
Kv flow factor: 1.2 to 2.8 L/min according to orifice based on water with 1 Bar pressure drop.
Seals: FKM standard, option NBR or EPDM.
Media: compressed air, vacuum, fuels, water and light oils and most other fluids under 40CST and gases compatible with materials of construction.
Coil: 11630 10 Watt IP65 CE DIN43650A Class F 100% duty rated
Coil: 31400 higher power 14-20 Watt IP65 CE DIN43650A Class F 100% duty rated
Protection: IP65 with connector (Included)
Voltage: 12vDC, 24vDC, 48vDC or 12vAC, 24vAC, 48vAC, 110vAC, 230vAC and 380vAC 50/60Hz.
The 300201 is one of our best selling miniature compact Brass 3 port 2 position solenoid valves and the preferred option for compressor drain, vegetable oil converted diesel vehicles and pneumatic actuator control.

Technical Specification

Brand: ERA SIB

Model: 300201

Width: 29.00 mm

Height: 87.00 mm

Depth: 41.00 mm

Weight: 0.28 kg

Valve / Product Type: Solenoid

Body Material: Brass

Voltage: 110vAC, 12vAC, 12vDC, 230VAC, 24vAC, 24vDC, 380vAC, 48vAC, 48vDC

Port Size: 1/4 Inch, 1/8 Inch

Function: 3/2 Normally Closed, 3/2 Normally Open, 3/2 Universal

Operation: Direct Acting

Pressure Maximum: 0.02 Bar (20 mBar), 0.1 Bar (100 mBar), 0.2 Bar (200 mBar), 0.3 Bar (300 mBar), 0.4 Bar (400 mBar), 0.5 Bar (500 mBar), 0.6 Bar (600 mbar), 0.7 Bar (700 mBar), 0.8 Bar (800 mBar), 1 Bar, 1.2 Bar, 1.3 Bar, 1.4 Bar, 1.5 Bar, 1.6 Bar, 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar, 12 Bar, 13 Bar, 14 Bar, 15 Bar

Seals: EPDM, NBR, FKM (Viton)

Approvals: IP65

Media: Air, Fluid >50cSt (Non Aggressive), Gases (Non Aggressive), Oils + Fuels >50cSt Max, Vacuum (Low), Water

Options required: Mounting Holes

Orifice: 1.5mm, 2.5mm, 2.0mm, 3.0mm
