Standpipe adaptor push-in airline fitting 4mm up to 12mm (NPGJ)

£6.19

incl. VAT
£5.16 ex. VAT

Brand: Shako Co Ltd

Model: NPGJ

Stock: 198 in stock

Read Full Description

Description

S-Line pneumatic Reducing Straight Coupler model NPGJ

Metric Tube Sizes from 4mm to 12mm

Larger Standard pipe to smaller push fit.

One Touch push to connect configuration allow an instant tubing connection

Strong engineering plastic (POM) sleeve and nickel plated brass body disconnection by pressing the sleeve and then simply removing the tube from the fitting

For use in pneumatic systems upto 9 Bar with maximum temperature of 60 degrees Celsius

Technical Specification

Brand: Shako Co Ltd

Model: NPGJ

Width: 10.00 mm

Height: 12.00 mm

Depth: 30.00 mm

Weight: 0.02 kg

Valve / Product Type: AirLine Fittings + Tube

Body Material: Brass, Delrin (POM)

Port Size: 4mm, 6mm, 8mm, 10mm, 12mm

Pressure Maximum: 0.02 Bar (20 mBar), 0.1 Bar (100 mBar), 0.2 Bar (200 mBar), 0.3 Bar (300 mBar), 0.4 Bar (400 mBar), 0.5 Bar (500 mBar), 0.6 Bar (600 mbar), 0.7 Bar (700 mBar), 0.8 Bar (800 mBar), 1 Bar, 1.2 Bar, 1.3 Bar, 1.4 Bar, 1.5 Bar, 1.6 Bar, 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar

Seals: NBR

Media: Air, Fluid (Non Aggressive), Gases (Non Aggressive), Water
