Key Features

Valve / Product Type: Solenoid Valve
Body Material: Ductile Iron
Voltage: 110vAC, 125vDC, 12vDC, 230VAC, 24vAC, 24vDC
Port Size: 4 inch Flange DN100 , 5 inch Flange DN125 , 6 inch Flange DN150 , 8 inch Flange DN200 , 10 inch Flange DN250, 12 inch Flange DN300 , 14 inch Flange DN350 , 16 inch Flange DN400 , 18 inch Flange DN450 , 2 inch Flange DN50, 20 inch Flange DN500 , 21/2 inch Flange DN65 , 3 inch Flange DN80
Function: 2/2 Failsafe Open
Operation: Pressure Assisted

Datasheets

DN50-500 Ductile iron solenoid valve 0.7-10 Bar 2/2 N/Open

£653.77 incl. VAT £544.81 ex. VAT

-40% Was ~~£1,089.61~~ incl. VAT

Select Valve Size / Model

Add To Cart

Brand: Z-Tide Co Ltd

Model: NOBFE-D

Stock: 54 in stock

Add to your wishlist

Read Full Description

Description

Flanged Ductile Iron Normally Open Solenoid Control Valve – Z-Tide Industrial NOBFE-D Series

The Z-Tide Industrial NOBFE-D Series is a premium flanged 2/2 way normally open ductile iron solenoid control valve designed for reliable control of water and compatible non-corrosive fluids in large bore pipelines. Featuring an externally piloted pressure-assisted piston design with patented anti-water hammer technology, the valve remains open during normal operation and closes when energised, making it ideal for fail-safe applications. Available from DN50 to DN1000 with PN16 flanges and optional ANSI 150 lb or JIS10K drilling, the NOBFE-D Series delivers exceptionally high flow rates while providing reliable operation in water treatment, pumping stations and industrial process systems.

Valve function & operation

Function: 2/2 way normally open

Manual override included

Operating principle: Pressure-assisted external pilot piston

Patented anti-water hammer design

Minimum operating pressure: 0.7 Bar differential

Flange sizes: DN50 to DN1000 PN16

Optional flange standards:

ANSI 150 lb

JIS10K

Other flange standards available on request

Pressure & flow

Pressure range: 0.7 to 10 Bar

Opening / closing time: 3 to 5 seconds

Maximum fluid viscosity: 50 cSt

Construction & materials

Body: Ductile iron with epoxy coating

Pressure tested to 32 Bar

Piston: Bronze

Seat: Bronze

Internals: Bronze and stainless steel

Spring: Stainless steel

Standard seals: NBR U-ring

Optional seals:

FKM (Viton)

EPDM

Media compatibility

✓ Water

✓ Potable and industrial water

✓ Cooling water

✓ Light oils up to 50 cSt

✓ Non-corrosive fluids compatible with the valve materials

Coil & electrical

Standard coil: M16

26 Watt DC

70 VA AC inrush

35 VA AC holding

Class F (155°C)

100% continuous duty rated

DIN43650A

IP65 protection

CE approved

Manual override included

IP65 connector supplied

Voltage options:

12V DC, 24V DC, 125V DC

24V AC, 110V AC, 230V AC 50/60 Hz

ATEX option

ATEX Ex mb IIC T4 Gb

ATEX Ex mb tb IIIC T130°C Db

Temperature Class T4

Suitable for Zones 21 & 22

Applications

Fail-safe water systems

Emergency cooling circuits

Water treatment plants

Pumping stations

Industrial process water systems

Cooling water circuits

Reservoir and storage tank control

Municipal water infrastructure

General industrial automation

Manufacturing quality

Manufactured using a heavy-duty epoxy-coated ductile iron body with bronze piston, bronze seating components and stainless steel internal parts, the Z-Tide Industrial NOBFE-D Series has been engineered for reliable long-term operation in demanding industrial environments. Its patented cylindrical piston design and externally piloted control system provide exceptionally high flow capacity while significantly reducing water hammer during operation. The removable external pilot assembly allows maintenance without removing the main valve body from the pipeline, reducing downtime and simplifying servicing. Designed for fail-safe applications, the normally open configuration ensures uninterrupted flow during normal operation while providing dependable shut-off when electrically energised.

Ordering information

Simply select the required flange size, seal material, voltage and flange standard before adding the valve to your basket. Optional ATEX coils and alternative flange standards are available to suit your application.

Related Products & Categories

Flanged Solenoid Valves

BF Series Multi-Functional Valve

Z Tide Manufacturing Product Range

View Technical Specification

Technical Specification

Brand: Z-Tide Co Ltd

Model: NOBFE-D

Width: 187.00 mm

Height: 187.00 mm

Depth: 190.00 mm

Weight: 12.00 kg

Valve / Product Type: Solenoid Valve

Body Material: Ductile Iron

Voltage: 110vAC, 125vDC, 12vDC, 230VAC, 24vAC, 24vDC

Port Size: 4 inch Flange DN100 , 5 inch Flange DN125 , 6 inch Flange DN150 , 8 inch Flange DN200 , 10 inch Flange DN250, 12 inch Flange DN300 , 14 inch Flange DN350 , 16 inch Flange DN400 , 18 inch Flange DN450 , 2 inch Flange DN50, 20 inch Flange DN500 , 21/2 inch Flange DN65 , 3 inch Flange DN80

Function: 2/2 Failsafe Open

Operation: Pressure Assisted

Pressure: 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar

Seals: EPDM, NBR, FKM (Viton)

Approvals:: IP65

Media: Fluid (Non Aggressive), Oils + Fuels 50cSt Max, Water

Options required: Anti Water Hammer, Manual Override

Orifice: 125mm, 150mm, 200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm, 50mm, 65mm, 80mm
