Air Line Swivel Y Union Push-to-Connect Fittings – NPY / NPW Series
Pneumatic Y Union with Twin Swivelling Outlets
The NPY and NPW Series pneumatic Y union fittings provide one inlet with two independently swivelling push-in outlet connections, allowing flexible routing of two air lines from a single supply.
Unlike a conventional fixed Y union, the two outlet branches can be repositioned to suit the installation, making the fitting particularly useful in compact machinery and pneumatic systems where tube direction needs to be adjusted.
Available in equal and reducing configurations for metric pneumatic tube sizes from 4mm to 10mm, subject to remaining clearance stock.
Twin Swivel Outlet Design
The two outlet connections can swivel independently, allowing each pneumatic tube to be directed to the required position.
This provides greater installation flexibility than a fixed Y connector and can reduce tube bending or unnecessary additional elbow fittings in confined installations.
Equal & Reducing Options
NPY models provide equal-size inlet and outlet connections.
NPW models provide a larger inlet feeding two smaller outlet tube connections, allowing the air line to be divided and reduced within a single compact fitting.
One-Touch Push-In Connections
Each port uses a one-touch push-in connection for quick tube installation without tools.
To disconnect, press the release sleeve while withdrawing the tube, allowing easy maintenance and pneumatic circuit modification.
Construction
Body: Engineering plastic POM
Tube Sleeves: Nickel-plated brass
Seals: NBR
Configuration: 1 inlet × 2 swivel outlets
Connections: Push-in tube
Tube Sizes: 4mm to 10mm
Versions: Equal and reducing
Pressure & Temperature
Operating Pressure: 0–9 Bar
Maximum Temperature: +60°C
Suitable Tubing: Nylon and polyurethane
Suitable Media: Compressed air and compatible non-aggressive gases
Typical Applications
Ideal for pneumatic cylinders, automation equipment, machinery, control panels, air distribution systems and installations requiring two independently adjustable outlet directions from a single air supply.
Clearance – GPY Current Alternative
The NPY / NPW Swivel Y Union Series is discontinued and available only while remaining stock lasts.
For new installations, the
GPY Y Union Push-In Fitting Series is the current alternative and is available in equal and reducing configurations.
Please note: the GPY uses a fixed Y body and does not provide the independently swivelling twin outlets of the NPY / NPW series.
