Push Fit Hand shut off valve 3/2 way airline vent 4mm-12mm
£3.36
Description
Air Line 3-Way Hand Shut-Off Valve with Downstream Vent – GHVFF Series
Compact, reliable, and safe 3-way pneumatic hand shut-off valve with integrated downstream vent for precise air circuit control. Ideal for isolating, venting, and testing pneumatic or vacuum systems.
Key Features
→ Function: 3-way hand-operated shut-off with downstream vent
→ Operation: Manual push-to-connect for instant tube engagement and release
→ Tube Compatibility: Polyurethane or Nylon tubing
→ Tube Sizes: Metric 4mm, 6mm, 8mm, 10mm, 12mm; equal or reducing versions
→ Operating Pressure: 0–10 bar (0–150 PSI)
→ Maximum Pressure: 15 bar (217 PSI)
→ Vacuum Rating: –1 bar (–100 kPa / –29.5 in Hg)
→ Temperature Range: –20 °C to +70 °C
Construction & Materials
→ Body: PA66
→ Back Ring, Seat & Push Rod: POM
→ Seals: NBR for positive air shut-off and venting control
→ Springs & Lock Claws: Stainless steel for secure retention and durability
→ Collet & Sleeve: Zinc alloy & POM for smooth, repeatable tube engagement
Applications
→ Isolating and venting pneumatic lines
→ Maintenance shut-off points in compressed air systems
→ Safety and testing applications
→ Vacuum systems and automation setups
Advantages
→ Quick installation and maintenance with push-to-connect design
→ Positive downstream venting for safe pressure release
→ Long-lasting, corrosion-resistant construction
→ Compact design for flexible integration into pneumatic circuits
The GHVFF Series provides dependable manual control for air and vacuum systems, combining ease of use, durability, and safety in one compact valve.
Technical Specification
Brand: Connexion
Model: GHVFF
Width: 43.20 mm
Height: 40.70 mm
Depth: 17.60 mm
Weight: 0.10 kg
Valve / Product Type: AirLine Fittings + Tube, Vacuum Breaker + Generators, Manual + Mechanical Control, Safety Shut Off
Body Material: Nylon
Port Size: 4mm, 6mm, 8mm, 10mm, 12mm
Operation: Direct Acting
Pressure: 0.02 Bar (20 mBar), 0.1 Bar (100 mBar), 0.2 Bar (200 mBar), 0.3 Bar (300 mBar), 0.4 Bar (400 mBar), 0.5 Bar (500 mBar), 0.6 Bar (600 mbar), 0.7 Bar (700 mBar), 0.8 Bar (800 mBar), 1 Bar, 1.2 Bar, 1.3 Bar, 1.4 Bar, 1.5 Bar, 1.6 Bar, 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar
Seals: NBR
Media: Air, Vacuum (Low), Vacuum (Medium), Vacuum (High)
Options required: Manual Control, Mounting Holes
Orifice: 4.0mm, 6.0mm, 8.0mm, 10mm, 12mm
