Standpipe adaptor push-in pneumatic fitting 4mm to 12mm
£0.46
£0.86 incl. VATDescription
ECO-Line Stand pipe adapter reducer Advanced Pneumatic Push-to-Connect Fittings GPPGJ
Metric Tube Sizes 4mm to 12mm.
Compact One Touch push to connect configuration allow an instant Nylon and Polyurethane tubing connection.
Construction: Body Polybutylene terephthalate (PBT), Sealing Ring & O Ring NBR, Collet (Zinc alloy), Sleeve + Lock Ring (POM), Lock claws (Stainless)
For use in pneumatic & vacuum systems
Working Pressure: 0-1MPa, 0-150 PSI, 0-10 Bar
Maximum Pressure: 1.5 MPa, 217 psi, 15 Bar
Vacuum Systems: -29.5 in Hg, -100kPa, -1 Bar
Temperature Range: -20 to +70C (-4F to +150F)
Tube: Polyurethane and Nylon
Technical Specification
Brand: Connexion
Model: GPPGJ
Width: 20.00 mm
Height: 50.00 mm
Depth: 20.00 mm
Weight: 0.10 kg
Valve / Product Type: AirLine Fittings + Tube
Body Material: Delrin (POM)
Port Size: 4mm, 6mm, 8mm, 10mm, 12mm
Seals: NBR
Media: Air, Vacuum (Low), Vacuum (Medium)
Pressure: Vacuum, 0.02 Bar (20 mBar), 0.1 Bar (100 mBar), 0.2 Bar (200 mBar), 0.3 Bar (300 mBar), 0.4 Bar (400 mBar), 0.5 Bar (500 mBar), 0.6 Bar (600 mbar), 0.7 Bar (700 mBar), 0.8 Bar (800 mBar), 1 Bar, 1.2 Bar, 1.3 Bar, 1.4 Bar, 1.5 Bar, 1.6 Bar, 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar
