3/8 WRAS Brass Solenoid Valve 0.5-10 Bar 2/2 Normally Closed PU225D-03

Brand: Shako Co Ltd

Model: PU225D-03

Dimensions
Width 48.00
Height 106.50
Length 66.50

£53.64 £98.86
Price Ex Vat: £44.70

100 in stock
Add To Cart
Add to Wishlist

Description

3/8 inch WRAS Brass solenoid valve Model PU225D-03
Function: 2/2 normally closed
Anti water hammer design, open / close 0.5 Seconds
Operation: pressure assisted (requires 0.5 Bar min pressure differential)
Pressure: 0.5 to 10 Bar differential, Max working 15 Bar
Port: 3/8 BSP, option NPT thread
Orifice: 13.0mm
Kv flow factor: 40 L/min based on water with 1 Bar pressure drop
Body: Brass
Internals: Stainless steel
Sealing: EPDM (WRAS approval 2304324)
Media: Water and other fluids under 50 CST and gases compatible with materials of construction.
Option: degreased, with all traces of oil and grease removed.
Temperature: -5°C to +130°C.
Coil: 15 Watt Nass Magnet Class H CE IP65 approved 100% duty rated DIN43650A
Protection: IP65 with connector (Included)
Coil option: ATEX EExmIIT4 Temperature Class T4 T130°C Ex mb IIC T4 and Gb Ex mb tb IIIC T130°C Db for hazardous area 21 and 22 with max media temperature +80°C.
Voltages: 12vDC, 24vDC, 48vDC, 110vDC, 220vDC or 12vAC, 24vAC, 36vAC, 48vAC, 110vAC, 220vAC, 240vAC or 380vAC 50/60hz.

Coil option: 22003L Latching coil 6vdc or 12vDC, power pulse stays open, reverse polarity power pulse will stay closed.
