1/8 BSP 5/2 Pneumatic Solenoid Valve Double Sol 18mm Body
£55.03 incl. VAT
Description
5/2 Way Double Acting Solenoid Valve AM52001D
Compact 5/2 way double acting solenoid valve with manual override, suitable for pneumatic systems requiring precise actuation and manifold mounting.
Valve function & operation
→ Function: 5/2 way double acting with manual override
→ Operation: Internal pilot
→ Port: 1/8 BSP, option NPT or Rc
→ Pressure range: 1.5 to 8 Bar, Max working 10 Bar
→ Orifice: 11 mm²
→ Temperature range: -10°C to +50°C
Construction & materials
→ Body: Aluminium alloy
→ Seals: NBR
→ Media: Compressed air and inert gases
Coil & electrical
→ Coil: 2.5 Watt IP65 Class F DIN43650C, 100% duty rated
→ Option: 30cm flying lead wire
→ Voltages: 12vDC, 24vDC, 24vAC, 110vAC or 230vAC
Special options
→ Base mount option: AM520DB
→ Suitable for manifold assembly, see MF520 in related items and select correct size option
Applications
→ Compact pneumatic control systems
→ OEM machinery requiring precise 5/2 way actuation
→ Automation panels and process control applications
Technical Specification
Brand: Shako Co Ltd
Model: AM520D
Width: 18.00 mm
Height: 34.50 mm
Depth: 138.00 mm
Weight: 0.51 kg
Valve / Product Type: Solenoid Valve
Body Material: Aluminium
Voltage: 110vAC, 12vDC, 230VAC, 24vAC, 24vDC
Port Size: 1/8 thread
Function: 5/2 Double Acting
Operation: Pressure Assisted
Pressure: 1.5 Bar, 1.6 Bar, 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar
Seals: NBR
Approval: ATEX,WRAS,IP etc: IP65
Media: Air, Gases (Non Aggressive)
Options required: Manifold, Manual Override
Orifice: 4.0mm
